Lenovo ThinkCentre neo 50q Gen 5 Intel Core 5 210H 16 GB DDR5-SDRAM 512 GB SSD Windows 11 Pro Mini PC Black

SKU
13B9001XAU
$1,116.97
In stock
Intel Core 5 210H, 8C (4P + 4E)/12T, P-core 2.2/4.8GHz, E-core 1.6/3.6GHz, 12MB, 2x 8GB SO-DIMM DDR5-5600, 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, Intel Graphics, Realtek Wi-Fi 7 RTL8922AE 802.11be 2x2 + BT5.4, No, Windows 11 Pro
  • Intel Core 5 210H, 8C (4P + 4E)/12T, P-core 2.2/4.8GHz, E-core 1.6/3.6GHz, 12MB
  • 2x 8GB SO-DIMM DDR5-5600
  • 512GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
  • Intel Graphics
  • Windows 11 Pro
More Information
SKU 13B9001XAU
EAN 0198158727242
Manufacturer LENOVO
Availability Y
Product Family ThinkCentre
Product Series neo
PDF URLs View PDF
View PDF
View PDF
View PDF
LENOVO ThinkCentre Neo 50q G5 Tiny Desktop PC i5-210H 16GB DDR5 512GB SSD Windows 11 Pro 1yrs Onsite Wty UHD Graphics WiFi6 KBM

Processor Intel® Core 5 210H, 8C (4P + 4E) / 12T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.6GHz, 12MB
Graphics Integrated Intel® Graphics
Chipset Intel® SoC Platform
Memory 2x 8GB SO-DIMM DDR5-5600
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 64GB DDR5-5600
Storage 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Max Storage Support Up to two drives, 2x M.2 SSD • M.2 SSD up to 1TB each
RAID Preset None
Card Reader No card reader
Optical None
Audio Chip High Definition (HD) Audio, Realtek® ALC256 codec
Speakers 2Wx1
Camera No camera
Microphone No microphone
Power Supply 90W 89% Adapter
DESIGN
Keyboard USB, Calliope, Black, English (US)
Mouse USB Calliope Mouse, Black
Optional Bay None
Expansion Slots Three M.2 slots (one for WLAN, two for SSD)
Case Color Black
Stand None
Adapter Cage None
Toolless Chassis Screw None
Mounting None
IO Box No IO box
Pen Pen Not Supported
Form Factor Tiny (1L)
Dimensions (WxDxH) Tiny only (without rubber feet) | 179 x 182.9 x 34.5 mm (7.05 x 7.2 x 1.36 inches)
Tiny only (with rubber feet) | 179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches)
Weight Around 1.13 kg (2.49 lbs)
CONNECTIVITY
WLAN + Bluetooth Realtek® Wi-Fi® 7 RTL8922AE, 802.11be 2x2 + BT5.4
WWAN Non-WWAN
Ethernet Integrated 100/1000M
Front Ports 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 5V@3A charging
1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging
1x headphone / microphone combo jack (3.5mm)
Rear Ports 2x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On
2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
1x HDMI® 2.1 TMDS
1x DisplayPort™ 1.4b
1x Ethernet (GbE RJ-45)
1x Power connector
Optional Rear Ports (configured) DP 1.4
Monitor Cable None
SECURITY & PRIVACY
Security Chip Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Fingerprint Reader No fingerprint reader
Physical Locks Kensington® Security Slot™, 3 x 7 mm
Chassis Intrusion Switch Chassis Intrusion Switch
MANAGEABILITY
System Management Non-vPro®
SERVICE
Base Warranty 1-year, Onsite



Processor
Processor frequency2.2 GHz
Processor familyIntel Core 5
Processor manufacturerIntel
Processor model210H
Processor cores8
Processor boost frequency4.8 GHz
Processor threads12
Memory
Internal memory16 GB
Internal memory typeDDR5-SDRAM
Maximum internal memory64 GB
Memory layout (slots x size)2 x 8 GB
Memory slots2x SO-DIMM
Memory clock speed5600 MHz
Storage
Total storage capacity512 GB
Optical drive typeNo
Card reader integratedNo
Storage mediaSSD
Number of SSDs installed1
SSD capacity512 GB
SSD interfacePCI Express 4.0
SSD form factorM.2
Total SSDs capacity512 GB
NVMeYes
Graphics
Discrete graphics cardNo
Discrete graphics card modelNot available
On-board graphics card modelIntel Graphics
On-board graphics cardYes
On-board GPU manufacturerIntel
Optical drive
Optical drive typeNo
Network
Ethernet LANYes
Ethernet LAN data rates100,1000 Mbit/s
Wi-FiYes
Wi-Fi standardsWi-Fi 7 (802.11be)
BluetoothYes
Bluetooth version5.4
Top Wi-Fi standardWi-Fi 7 (802.11be)
Antenna type2x2
Ports & interfaces
Combo headphone/mic portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
Thunderbolt 3 ports quantity0
USB 2.0 ports quantity2
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity1
Ethernet LAN (RJ-45) ports1
Design
Product colourBlack
Volume1 L
Chassis typeMini PC
Cable lock slotYes
Cable lock slot typeKensington
Colour nameBlack
Performance
Audio chipRealtek ALC256
Number of speakers1
Product typeMini PC
Motherboard chipsetIntel SoC
Audio systemHigh Definition Audio
Trusted Platform Module (TPM)Yes
Software
Operating system installedWindows 11 Pro
Operating system languageEnglish
Power
Power supply90 W
Certificates
CertificationENERGY STAR,TCO,RoHS
Weight & dimensions
Volume1 L
Width179 mm
Depth182.9 mm
Height34.5 mm
Weight1.13 kg
Packaging content
Mouse includedYes
Keyboard includedYes
Mouse connectivityWired
Keyboard connectivityWired
Other features
Number of speakers1
Processor manufacturerIntel
Trusted Platform Module (TPM)Yes
On-board graphics cardYes
